| Kamera |
| Görüntü Sensörü: |
| |
1/2.8" Progressive Scan CMOS |
| İşaret Sistemi: |
| |
PAL/NTSC |
| Minimum Aydınlatma: |
| |
Color: 0.005 lux @(F1.2, AGC ON), 0 lux with IR |
| Objektif Hızı: |
| |
1/3 s to 1/100,000 s |
| Slow shutter: |
| |
Support |
| Lens: |
| |
2.8 mm, horizontal field of view: 108°
4 mm, horizontal field of view: 86.4°
6 mm, horizontal field of view: 52°
8 mm, horizontal field of view: 40°
12 mm, horizontal field of view: 25° |
| Lens Kurulumu: |
| |
M12 |
| Ayarlanan Aralık: |
| |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Gündüz & Gece: |
| |
IR cut filter with auto switch |
| Geniş Dinamik Aralık: |
| |
120 dB |
| Dijtal Gürültü Azaltma: |
| |
3D DNR |
| Sıkıştırma Standardı |
| Video Bit Hızı: |
| |
32Kbps~16Mbps |
| Üçüncü Akım: |
| |
Yes |
| Görüntü |
| Maksimum Çözünürlük: |
| |
1920 x 1080 |
| Çerçeve Hızı: |
| |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280×720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280×720) |
| Ana Akış: |
| |
50Hz: 25fps (640 × 360, 352 × 288)
60Hz: 30fps (640 × 360, 352 × 240) |
| Üçüncül Akış: |
| |
50Hz: 25fps (1920 × 1080, 1280×720, 640 × 360, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280×720, 640 × 360, 352 × 240) |
| Görüntü İyileştirme: |
| |
BLC/3D DNR |
| Görüntü Ayarlama: |
| |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Bölgesel Kırpma: |
| |
Support |
| ROI: |
| |
Support 1 fixed region for each stream, and face dynamic tracking |
| Gündüz / Gece Anahtarı: |
| |
Auto/Scheduled |
| Ağ |
| Protokoller: |
| |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| Güvenlik: |
| |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy
mask, Watermark, IP address filtering, Anonymous access |
| Sistem Uyumluluğu: |
| |
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI |
| Arayüzü |
| İletişim Arayüzü: |
| |
1 RJ45 10M / 100M Ethernet interface |
| Dahili Depolama: |
| |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Akıllı Özellik-set |
| Sınır İhlali: |
| |
Cross a pre-defined virtual line |
| Saldırı Algılama: |
| |
Enter and loiter in a pre-defined virtual region |
| Bırakılan Eşya: |
| |
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Alınan Eşya: |
| |
Objects removed from the pre-defined region, such as the exhibits on display. |
| Genel |
| Çalışma Sıcaklığı: |
| |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Güç Kaynağı: |
| |
12 VDC ± 25%, PoE (802.3af Class3) |
| GÜç Tüketimi: |
| |
12 VDC ± 25%, 5W
PoE(802.3af, class 3), 6.5W |
| Weather Proof: |
| |
IP67 |
| IR Aralık: |
| |
Up to 30m |
| Boyutlar: |
| |
Camera: Φ70 × 155.03 mm (Φ2.76″ × 6.1″)
Package: 216 × 121 × 118 mm (8.5″ × 4.76″ × 4.65″) |
| Ağırlık: |
| |
Camera: 410 g (0.9 lb.) |
