Camera
|
|
Image Sensor
|
1/2.7” 2Megapixel progressive scan CMOS
|
|
Effective Pixels
|
1920(H) x 1080(V)
|
|
RAM/ROM
|
64MB/16MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual, 1/3~1/100000s
|
|
Minimum Illumination
|
0.009Lux/F2.0( Color,1/3s,30IRE)
0.05Lux/F2.0( Color,1/30s,30IRE)
0Lux/F2.0(IR on)
|
| S/N Ratio |
More than 50dB |
|
IR Distance
|
Distance up to 30m(98ft)
|
|
IR On/Off Control
|
Auto/Manual
|
|
IR LEDs
|
1
|
|
Lens
|
|
Lens Type
|
Fixed
|
|
Mount Type
|
Board-in
|
|
Focal Length
|
3.6
|
|
Max. Aperture
|
F2.0/F2.0
|
|
Angle of View
|
H:115°/87.5°, V:60°/47°
|
|
Focus Control
|
Fixed
|
| Close Focus Distance |
0.5m(1.64ft) |
|
DORI Distance
|
| Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
43.5m(143ft) |
17.4m(57ft) |
8.7m(28.5ft) |
4.3m(14ft) |
| 3.6 mm |
53.3m(175ft) |
21.3m(70ft) |
10.7m(35ft) |
5.3m(17.4ft) |
|
Pan/Tilt/Rotation
|
|
Pan/Tilt/Rotation Range
|
Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°
|
| Video |
| Compression |
H.265/H.264H/MJPEG(Sub Stream)
|
| Smart Codec |
Support H.265+/H.264+ |
| Streaming Capability |
2 Streams |
| Resolution |
1080P(1920×1080)/1.3M(1280x960)/
720P(1280×720)/D1(704×576/704×480)/
VGA(640×480)/CIF(352×288/352×240)
|
| Frame Rate |
Main Stream: 1080P(1~25/30fps) |
| Sub Stream: D1(1~25/30fps) |
| Third Stream: 1080P(1~5/0fps) |
| Bit Rate Control |
CBR/VBR |
| Day/Night |
Auto(ICR) / Color / B/W |
| BLC Mode |
BLC / HLC / DWDR |
| White Balance |
Auto/Natural/Street Lamp/Outdoor/Manual |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detetion |
Off / On (4 Zone, Rectangle) |
| Region of Interest |
Off / On (4 Zone) |
|
Electronic Image Stabilization
(EIS)
|
N/A |
| Smart IR |
Support |
| Defog |
N/A |
| Digital Zoom |
16x |
| Flip |
0°/90°/180°/270° |
| Mirror |
Off / On |
| Privacy Masking |
Off / On (4 Area, Rectangle) |
| Audio |
| Compression |
N/A |
